Integra DPS-5.4 Service Manual

Exploded V
U5 Inlet terminal PC board assy 1H505502-1H NAPS-8002-1H
<MUA>
Exploded V
U6 Support PC board 1H505503-1G NAETC-8003-1G
<MDD, MDC>
Exploded V
U6 Support PC board 1H505503-1H NAETC-8003-1H
<MUA>
Exploded V
U7 RS-232 terminal PC board assy 1H505505-1G NAETC-8005-1G
<MDD, MDC>
Exploded V
U7 RS-232 terminal PC board assy 1H505505-1H NAETC-8005-1H
<MUA>
Exploded V
U20 Power supply unit
!
24150040 NGPS-0040-100-120V
<MDD, MDC>
Exploded V
U20 Power supply unit
!
24150041 NGPS-0041-100-240V
<MUA>
NOTE: <MDD>: North American area
<MDC>: Canadian area
<MUA>: Australian area
PACKING PARTS LIST
DPS-5.4
Packing V REF. NO. PART NAME PART NO. DESCRIPTION REMARK
Packing V
A450 CARTON 29054065A DPS-5.4MDD
<MDD, MDC, MU
A
Packing V
A451 LABEL 29363464 (RE)MUA4P
<MUA>
Packing V
A455 UPC LABEL 29363446 DPS-5.4(B)
Packing V
A530 WARRANTY CARD 29365089 (INTEGRA)
<MDD, MDC>
Packing V
<MUA> supplied from
Sales Dep.
Packing V
A601 PAD 29092099B (AS)
Packing V
A604 POLY BAG 29100037-1A 650*500
Packing V
A605 POLY BAG 29100097-1A 350*250
Packing V
A607 PP TAPE 29110148 W48 OPP TAPE 1.3MT
Packing V
A901 CORD AS 2010412 RCA3P(YWR)
Packing V
A901 or PIN CORD AS 2010379 RCA3P(YWR)
Packing V
A902 BATTERY 3010054 R6/AA(UM-3)
Packing V
A903 PLUG CORD 2010200 3.5-MINI PLUG (RI)
Packing V
A905 REMO CON 24140536 RC-536DV
Packing V
A906 CORD AS 2010380 (S CORD)
Packing V
A906 or CORD AS 2010360 TPX3000
Packing V
A911 INS MANUAL 29343491 En(DPS-5.4)
Packing V
P981 AC CORD
!
253352TES AS-UC-2
<MDD, MDC>
Packing V
P981 or AC CORD
!
253297KAW AS-UC-2
<MDD, MDC>
Packing V
P981 AC CORD
!
253311VOL AS-SAA
<MUA>
NOTE:
<MDD>: North American area
<MDC>: Canadian area
<MUA>: Australian area
PRINTED CIRCUIT BOARD PARTS LIST DPS-5.4
U1 : OUTPUT TERMINAL PC BOARD NAAR-7997
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
AR-7997
Q352 IC 22274004HR2O TC74VHCU04FT
AR-7997
Q401 IC 22241448R2 NJM4580M-D
AR-7997
Q402 IC 22241448R2 NJM4580M-D
AR-7997
Q403 IC 22241448R2 NJM4580M-D
AR-7997
Q404 IC 22241448R2 NJM4580M-D
AR-7997
Q405 TR 2216141R2 HN1C03F-B
AR-7997
Q406 TR 2216141R2 HN1C03F-B
AR-7997
Q407 TR 2216141R2 HN1C03F-B
AR-7997
Q460 TR 2216480R2 DTA114YKA
AR-7997
Q460 or TR 2216360R2 RN2407
AR-7997
Q460 or TR 2216350R2 KRA107S
AR-7997
Q463 TR 2216470R2 DTC114YKA
AR-7997
Q463 or TR 2216260R2 RN1407
AR-7997
Q463 or TR 2216340R2 KRC107S
AR-7997
Q806 TR 2216706R2 UMG9N
AR-7997
Q920 TR 2216175R2 KTC3875-GR
AR-7997
Q920 or TR 2213145R2 2SC2712-GR
AR-7997
Q351 PHT CP 24120102 TOTX179L
AR-7997
Q801 PHT CP 24120043 ON3131
