Connecting speakers

You can select the layout of speakers to be installed from various patterns when using this unit. Use the following ow chart to select the speaker layout that suits your

speakers and usage environment. You can check the connection method and default settings. Dolby Atmos ( p92) listening mode faithfully reproduces the sound

design recorded in the Dolby Atmos audio format by installing Surround Back Speakers or Height Speakers. Dolby Atmos enables the accurate placement of sound

objects that have independent motion in a three-dimensional space with even greater clarity.

Yes No

Do you enjoy sound with Dolby Atmos?

 When using Surround Back

Speakers

• 7.1 Channel System (

p37)

• 7.1 Channel System + ZONE

SPEAKER ( p38)

• 7.1 Channel System (Bi-Amping

the Speakers) ( p39)

 When using 1 set of Height
