❏ Dolby Enabled Speakers (Dolby Speakers)
Installation Example
*3
*1
*2
9bk
9
9bk
bk
*1: 22° to 30°, *2: 90° to 110°, *3: 135° to 150°
This is a system with the 7.1 channel system ( p15) consisting of front
speakers, a center speaker, surround speakers, surround back speakers and a
powered subwoofer, and added Dolby enabled speakers (front), Dolby enabled
speakers (surround) or Dolby enabled speakers (surround back) combined.
Dolby enabled speakers are special speakers designed to face the ceiling, so
that the sound is heard from overhead by bouncing the sound o the ceiling. By
installing such height speakers, when the input format is Dolby Atmos, you can
select the Dolby Atmos listening mode which realizes the most up-todate 3D
sound including overhead sound.
Install them either on the front speakers, on the surround speakers or on the
surround back speakers.
9,10 Height Speakers
Choose one of the following:
• Dolby Enabled Speakers (Front)
• Dolby Enabled Speakers (Surround)
• Dolby Enabled Speakers (Surround Back)
