U2
SECONDARY POWER
SUPPLY PC BOARD ASSY
NAPS-7789 1A953589-1A
U3
INLET PC BOARD ASSY
NAETC-7801 1A953501-1A
U4
TEMPERATURE SENSOR
PC BOARD ASS
NAETC-7803 1A953503-1A
U5
SWITCHING CONTROL PC
BOARD ASS
NAPS-7790
1A953590-1A
U6
12V TRIGGER TERMINAL
PC BOARD ASS
NAPS-7792 1A953592-1A
U7
CONTROL PC BOARD
NAPS-7793 1A953593-1A
U8
DISPLAY LED PC BOARD
ASS
NAETC-7794 1A953594-1A
U9
POWER SWITCH PC
BOARD ASS
NASW-7795 1A953595-1A
U10
POWER SWITCH HOLDER
PC BOARD ASS
NAETC-7796 1A953596-1A
U11
TEMPERATURE SENSOR
PC BOARD ASSY BOAR
NAETC-7802 1A953502-1A
U12
HOLDER PC BOARD ASSY
BOARD
NAETC-7804 1A953504-1A
U14
TERMINAL PC BOARD
NAPS-7791 1A953591-1A
U15
POWER AMPLIFIER PC
BOARD ASS
NAAF-7797
1A953597-1A
U16
TEMPERATURE SENSOR
PC BOARD ASSY BOAR
NAAF-7798 1A953598-1A
PC BOARD
PARTS LIST
DTA-9.4
U1 PRIMARY POWER
SUPPLY PC BOARD
NAPS-7788-1A
REF NO. PART NAM
DESCRIPTIO
PART NO. NOTE
D903 DIODE D1NL40 22380323
D904 DIODE D1NL40 22380323
D905 DIODE D1NL40 22380323
D906 DIODE D1NL40 22380323
D907 LED SEL4110
225290
D931 DIODE 1SS133 223163
D941 DIODE EK16 22380329F
D942 DIODE EK16 22380329F
D943 DIODE EK16 22380329F
D944 DIODE EK16 22380329F
L901 CHOKE COI
NCH-3596 231319
!
L904 CHOKE COI
NCH-1594 231317180
L906 CHOKE COI
NCH-3597 231320
L912 FR CORE BL02RN2-R62 230906
L913 FR CORE BL02RN2-R62 230906
L941 CHOKE COI
NCH-1602 231326A
P101 CRIMP AS CRIMP AS 206CC56080UL
T901 SW TRANS NSWT-3025 231312
T902 SW TRANS NSWT-3025 231312
C901 IS C DE1607F103M-KH 3300031S
!
C902 IS C QETJ5105KRP2CS 3800037S
!
C903 IS C DE1E3KX152MB5B
3300062S
!
C904 IS C DE1E3KX152MB5B
3300062S
!
