Features
■ High output switching power supply dedicated to
audio processing
■ Ultra low impedance design with extensive use of
copper bus bar, large coil, and ultra heavy gauge
wire
■ 7-channel integral PWM amplifier with completely
discrete structure
■ Balanced XLR Inputs for Better Dynamic Range
and Stability on long Cable Runs
■ Gold plated high quality grinded speaker terminals
and RCA/XLR input terminals
■ High quality custom speaker terminals
compatible with banana plugs
■ 12V trigger input terminal
■ Detachable power cord
■ 120 Watts per channel min. RMS. Into 8 ohms 2
channel driven, from 20 to 20,000 Hz with no
more than 2.5 % total harmonic distortion
Contents
Before using
Important Safeguards......................................... 2
Precautions ......................................................... 3
Features ............................................................... 4
Contents .............................................................. 4
Supplied accessories ......................................... 5
Precautions ......................................................... 6
Operations
Quick operation guide ........................................ 7
Front panel facilities ........................................... 8
Connections
Rear panel facilities and connections .............. 9
Connecting speakers ....................................... 11
Connecting to the Integra AV Controller
DTC-9.4 ......................................................... 12
Appendix
Troubleshooting guide ..................................... 13
Specifications ................................................... 14
