20/41 PAGE
PCB1
JL918B WIRE HOL NSCT-5P896 1 25051109
PCB2
U07
MICROPROCESSOR PC BOARD (NADG-9619-1A)
PCB2
U08
DISPLAY PC BOARD (NADIS-9620-1A)
PCB2
U09
THERMAL SENSOR PC BOARD (NAETC-9621-1A)
PCB2
U11
POWER SUPPLY PC BOARD (NAPS-9623-1A)
PCB2
U12
TRANS. PRI. TERMINAL PC BOARD (NAETC-9624-1A)
PCB2
U13
INLET PC BOARD (NAETC-9625-1A)
PCB2
U14
VOLUME PC BOARD (NAETC-9626-1A)
PCB2
U15
VIDEO PC BOARD (NAVD-9627-1A)
PCB2
U16
HEADPHONE JACK PC BOARD (NAETC-9628-1A)
PCB2
PCB2
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB2
U851 REMO SENS NJL34H380A 1 241365
PCB2
Q251 IC LA7956-E 1 22241759
PCB2
Q252 IC LA7956-E 1 22241759
PCB2
Q253 TR KTA1504-GR 1 2216185R2
PCB2
Q253 or TR 2SA1162-GR (1) 2214375R2
PCB2
Q254 TR RN1404 1 2214490R2
PCB2
Q255 TR RN1404 1 2214490R2
PCB2
Q256 TR RN1404 1 2214490R2
PCB2
Q257 TR RN1441 1 2215410R2
PCB2
Q258 TR RN1441 1 2215410R2
PCB2
Q259 TR RN1441 1 2215410R2
PCB2
Q701 IC (MAIN MICROPROCESSOR) M3062LFGPFP U5(0270) 1 222W0048R302700
PCB2
Q702 IC S-812C56AUA-C3K 1 22242207R2
PCB2
Q703 TR KRC104S 1 2216210R2
PCB2
Q703 or TR RN1404 (1) 2214490R2
PCB2
Q704 TR KRA102S 1 2216220R2
PCB2
Q704 or TR RN2402 (1) 2214530R2
PCB2
Q705 TR KRA102S 1 2216220R2
PCB2
Q705 or TR RN2402 (1) 2214530R2
PCB2
Q706 TR KRA102S 1 2216220R2
