Appendix
En-91
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels: (North American)
80 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.7% (FTC)
(Others)
5 ch × 130 W at 6 ohms, 1 kHz, 1 ch driven
of 1% (IEC)
Maximum Effective Output Power
(Others)
5 ch × 160 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
180 W (3 Ω, Front)
160 W (4 Ω, Front)
100 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
Rated RCA Output Level and Impedance
200 mV/2.2 kΩ (LINE OUT)
Maximum RCA Output Level and Impedance
2 V/2.2 kΩ (LINE OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (DSP bypass)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
FM Tuning Frequency Range
(North American) 87.5 MHz - 107.9 MHz
(Others) 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply (North American) AC 120 V, 60 Hz
(Others) AC 230 V, 50 Hz
Power Consumption (North American) 4.2 A
(Others) 400 W
No-sound Power Consumption
60 W
Stand-by Power Consumption
(North American) 0.15 W
(Others) 0.2 W
Dimensions (W × H × D)
435 mm × 174.5 mm × 326.5 mm
17-1/8" × 6-7/8" × 12-7/8"
Weight (North American) 8.8 kg (19.4 lbs.)
(Others) 9.2 kg (20.3 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6, IN 7
Output OUT
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, LipSync, CEC (RIHD)
Component IN 1, IN 2
Composite IN 1, IN 2, IN 3, IN 4, AUX
Component OUT
Composite MONITOR OUT
Digital Optical: 2
Coaxial: 2
Analog BD/DVD, CBL/SAT, GAME, PC, TV/CD,
AUX
Analog ZONE2 PRE/LINE OUT
Surround Back/Front High Pre Outputs
2 (SBL/FHL, SBR/FHR)
Subwoofer Pre Outputs
2
Speaker Outputs Main (L, R, C, SL, SR)
Phones 1 (6.3 ø)
Setup Mic 1
RI 1
RS232 1
USB 1 (Front)/1 (Rear)
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out A, B, C
