DTR-4.5
SPECIFICATIONS
Amplier Section
Video Section
Tuner Section
FM
AM
General
Video Inputs
Video Outputs
Audio Inputs
Audio Outputs
Other Jacks
Specifications and features are subject to change without
notice.
Power Output
(2 channels driven):
85 W + 85 W (8 ,20Hz–20kHz, FTC)
120 W +120 W (6 ,1kHz,DIN)
150 W + 150 W (6
,1kHz,JEITA)
Dynamic Power 220 W + 220 W (3
,Front)
165 W + 165 W (4
,Front)
100 W + 100 W (8
,Front)
THD (Total Harmonic
Distortion)
0.08 % (Power Rated)
Damping Factor 60 (Front,1kHz,8
)
Input Sensitivity and
Impedance
200 mV/ 47 k
(LINE)
Output Level and
Impeadance
200 mV/ 470 (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
SN Ratio 106 dB (LINEIHF-A)
Speaker Impedance 6
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75 (Component and S-Video Y)
0.7 Vp-p /75 (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 (S-Video C)
1 Vp-p /75 (Composite)
Component Video
Frequency Response 5 Hz – 50 MHz
Tuning Frequency Range
87.5 MHz– 107.9 MHz
Usable Sensitivity Stereo:17.2 dBf 2 µV(75 IHF)
Mono: 11.2 dBf 1 µV(75 IHF)
S/N Ratio Stereo: 70 dB (IHF-A)
Mono:76 dB (IHF-A)
THD Stereo: 0.3 % (1kHz)
Mono:0.2 % (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 45 dB ( 1kHz )
Tuning Frequency Range
530 kHz–1700 kHz
Usable Sensitivity 30 µV
S/N Ratio 40 dB
THD 0.70%
Power Supply AC 120 V, 60 Hz
Power Comsumption 5.7A
Stand-by Power
Comsumption 1.0 W
Dimensions(W x H x D) 17-1/8" W x 6-7/8" H x 16-7/8" D inches
Weight 13.4 kg
27.6 lbs
Component Video Input 1,2,3
S-Video Compatible Jack
Input DVD,VIDEO1,VIDEO2,VIDEO3
A/V Input DVD,VIDEO1,VIDEO2,VIDEO3
Component Video
Output OUT
S-Video Compatible Jack
Output MONITOR OUT,VIDEO1,VIDEO2
A/V Output MONITOR OUT,VIDEO1,VIDEO2
Digital Inputs Optical : 2
Coaxial : 2
Analog Inputs DVD(MULTICHANNEL),VIDEO1,
VIDEO2,VIDEO3,TAPE,CD
Multichannel Inputs 6
Digital Output 1 (Optical )
Analog Outputs TAPE,VIDEO1,VIDEO2
Subwoofer Pre Output 1
Speaker Outputs 7
Phones 1
RS-232 Control 1
IR Input/Output 1
12V Trigger Out
