TX-SR803/E

SERVICE PROCEDURES

F9001 252164 or 5A-UL/T-237 or

252258 5A-T/UL-ST2,Fuse <D/DT>

252241 or 2.5A-SE-TL250V or

252075 2.5A-SE-EAK,Fuse <P/GT/A/K>

F9501,F9502 252198 or 8A-UL or

252261 8A-T/UL-ST2,Fuse <D>

252166 or 6.3A-UL/T-237 or

252260 6.3A-T/UL-ST2,Fuse <DT>

252245 or 6.3A-SE-TL250V or

252079 6.3A-SE-EAK,Fuse <P/GT/A/K>

F9503,F9504 252160 or 2.5A-UL/T-237 or

252254 2.5A-T/UL-ST2 <D/DT>

252241 or 2.5A-SE-TL250V or

252075 2.5A-SE-EAK,Fuse <P/GT/A/K>

1. Replacing the fuses

This symbol located near the fuses indicates that the

fuse used is fast operating type. For continued protection against

fire hazard, replace with same type fuse. For fuse rating refer to

the marking adjacent to the symbol.

Ce symbole indique que le fusible utlise est a rapide.

Pour une protection permanente, n'untiliser que fusibles de

meme type. Ce darnier est la qu le present symbol est

appse.

CIRCUIT NO. PART NO. DESCRIPTION

2. To initialize the unit

This device employs a microprocessor to perform various

functions and operations. If interference generated by an external

power supply, radio wave, or other electrical source results in

accident which causes the specified operations and functions to

operate abnormally.

To perform a result, please follow the procedure below.

1.Press and hold down the VIDEO-1 button, then press the

STANDBY button.

2.After "CLEAR" is displayed, the preset memory and each

mode stored in the memory, such as surround, are

initialized and will return to the factory setting.

Note: <D>:120V model only

<P>: European model only

<GT>: Asian model only for 230V

<DT>:Asian model only for 120V

<A>: Australian model only

<K>: Korean model only

3. Safety-check out

(U.S.A. model only)

After correcting the original service problem, perform the

following safety check before releasing the set to the customer.

Leakage Current Check

Measure leakage current to a known earth ground(water pipe,

conduit, etc.) by connecting a leakage current tester between

the earth ground and exposed metal parts of the appliance

(input/output terminals, screwheads,metal overlays, etc.).

Plug the power supply cord directly into a 120V AC 60 Hz outlet

and turn Standby switch on. Any current meausred must not

exceed 0.5mA.

RDC-7.1

"Not available with Headphones use"

Operation not allowed while a pair of headphones is con-

nected.

"Not available in this Sp Config"

Doesn'

t w

ork with the current speaker configuration.

"Only available with Dolby D"

Can be used with only Dolby Digital.

"Not available with this signal"

Doesn't work with the current listening mode.

"Not available with Muting"

Operation not allowed because the RDC-7.1 is currently

muted.

"Not available in this Listening Mode"

Doesn't work with the current listening mode.

"Not available with NET AUDIO use"

Operation not possible with Net Audio selected for the

input source.

"Not available with Dolby Headphone Off

Doesn't work with the Dolby Headphone function off.

"Not available with Dolby Headphone On"

Doesn't work with the Dolby Headphone function on.

Not available with zone2 out in Line out"

Operation not possible with " 1-8. f. Zone 2 Out" set to

"Line Out."

Not available with zone3 out in Line out"

Operation not possible with "1-8. g. Zone 3 Out" set to

"Line Out."

4.Error Messages

5.Memory backup

The RDC-7.1 uses a battery-less memory backup sys-

tem in order to retain radio presets and other settings

when it is unplugged or in the case of a power failure.

Although no batteries are required, the RDC-7.1 must

be plugged into an AC outlet in order to charge the

backup system.

(On other than USA, Canadian, and Australian models,

the RDC-7.1's

wer switch must be set to On in order

to charge the backup system). Once it has been

charged, the RDC-7.1 will retain the settings for several

weeks, although this depends on the environment and

time will be shorter in humid climates.
