Specifications
- 10 -
Specifications
General
Channels 40 FM (refer to the frequency bands table at page 8)
Frequency range 27 MHz Citizen Band
Frequency control P.L.L.
Operatine temperature -10°/+55°C
DC input voltage 13.2Vdc ±15%
Size 100 (L) x 37 (H) x 180 (D) mm
Weight 690 gr.
Receiver
System Double conversion, CPU controlled super-heterodine
IF 1° 10.695 MHz / 2° 455 KHz
Sensitivity 0.5uV for 20dB SINAD (FM)
0.5uV for 20dB SINAD (AM)
Audio output 2.5W
Audio distorsion <8% at 1 KHz
Image rejection 65dB
Adjacent channel 65dB
Signal/noise ratio 45dB
Current drain 350mA (stand-by)
Transmitter
System CPU controlled P.L.L. systhesizer
Maximum RF power 4W at 13.2Vdc
Modulation 85% to 90% (AM)
1.8 KHz ±0.2 KHz (FM)
Impedance 50 ohm unbalanced
Current drain 1300mA (at no modulation)
English
