Customer : M-490 Plus Rev,Date:
No. Part No. Part name & Description Q’ty Ref.
115 133-936-1Y CHIP CERAMIC 390PF GRM39 COG391J 50V PT 1 C333
116 134-012-1Y CHIP CERAMIC 4PF GRM39 COG040C 50V PT 1 C326
117 134-757-1Y CHIP CERAMIC 47PF GRM39 COG470J 50V PT 4 C101.328.447.R901
118 135-021-4Y CHIP CERAMIC 5PF GRM39 COG050C 50V PT 1 C34
119 136-014-3Y CHIP CERAMIC 6PF GRM39 COG060D 50V PT 2 C422.426
120 136-839-2Y CHIP CERAMIC 68PF GRM39 COG680J 50V PT 2 C207.337
121 138-011-0Y CHIP CERAMIC 8PF GRM39 COG080D 50V PT 1 C114
122 138-232-3Y CHIP CERAMIC 82PF GRM39 COG820J 50V PT 3 C2.118.331A
123 138-249-0Y CHIP CERAMIC 820PF GRM39 C0G821J 50V 1 C457
124 202-085-9Z TRANSISTOR KRC101SNA 8 Q103.104.114.403.404.405.406.
418
125 202-095-8Z TRANSISTOR KRC104SND 5 Q3.4.9.10.602
126 202-098-1 BRT KRC102S 2 Q202.212
127 202-099-2Z TRANSISTOR KRC111SNM 1 Q2
128 202-106-5 TRANSISTOR KTA1504SY 5 Q115.118.205.208.213
129 202-112-0 TRANSISTOR KTC3875S(GR) 3 Q107.601.603
130 202-114-2 TRANSISTOR KTC3876ST1(Y) 11 Q1.7.11.112.113.204.207.211.
215.409.415
131 202-129-6Z TRANSISTOR KRC112ST1 1 Q8
132 202-153-7 TRANSISTOR KTC3880SY 9 Q6.102.116.117.301.302.408.411
.412
133 202-183-4 FET KTK211GR 2 Q105.106
134 218-039-1Z TRANSISTOR KRA101S 1 Q18
135 220-048-2Y I.C FM IF TK14489V 1 IC102
136 221-460-5 I.C PLL(DUAL) BU2630F 1 IC6
137 221-531-6 I.C CPU(OTP) S3P8249XZZ-TWR9 (NIKE) 1 IC101
138 221-717-8 I.C COMPANDER DBL5020V (SOP) 1 IC601
139 221-854-8 I.C EEPROM 24LLC02-A 1 IC9
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 43 / 61
Model No: 3390 Title Drawring No:
