Intek M-490 Plus - Page 42

Customer : M-490 Plus Rev,Date:
No. Part No. Part name & Description Q’ty Ref.
140 222-018-5A I.C KIA324F-EL 1 IC2
141 222-023-9A I.C DETECTOR KIA7042F 1 IC1
142 223-224-9 I.C MC14066BDR2:SO14 1 IC602
143 242-024-6 DIODE VARIVAP CHIP KDV251S 2 D402.403
144 243-051-5 DIODE SI CHIP KDS184S 21 D1.2.3.4.5.6.56.101.102.103.
104.122.153.154.203.301.302. +
303.407.413.414
145 401-179-B P.C.B MAIN 153.5 X 167.7 X 1.6T FR4 1/1 1
146 533-90M-PM MP MANUAL ASS'Y 1
147 018-220-5Y METAL OXIDE RESISTOR22 1W 5% ST 1 R237
148 018-221-6X METAL OXIDE RESISTOR220 1W 5% ST 1 R26
149 019-479-8X METAL OXID RESISTOR 4.7 2W 5% ST BULK 1 R207
150 030-100-6Z FILM RESISTOR 10 1/ 2W 5% ST MINI 1 R225
151 030-229-0Z FILM RESISTOR 2.2 1/ 2W 5% ST MINI 1 R314
152 030-472-2Z FILM RESISTOR 4.7K 1/ 2W 5% ST MINI 1 R315
153 030-479-3Z FILM RESISTOR 4.7 1/ 2W 5% ST MINI 1 R312
154 061-110-9 RESISTOR SEMIFIXED 100KB PC805M H 8DIA 1 RV101
155 061-205-2 RESISTOR SEMIFIXED 2KB PC805M H 8DIA 2 RV201.401
156 061-206-3 RESISTOR SEMIFIXED 20KB PC805M H 8DIA 1 RV1
157 061-508-8 RESISTOR SEMIFIXED 50KB PC805M H 8DIA 2 RV2.202
158 098-201-2 THERMISTOR DISK 200 OHM 15%:KC5B120L 3 TH1.102.105
159 098-501-3 THERMISTOR DISK 500 KC5C150L 1 TH55
160 100-101-9Y ELECT CAPACITOR 0.1UF 50V 20% 5X11 2 C131.433
161 101-A02-8Y ELECT CAPACITOR 1000UF 25V 20% 10X20 4 C6.212.213.216
162 101-006-2Y ELECT CAPACITOR 1UF 50V 20% 5X11 2.5PT 3 C153.448.452
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 44 / 61
Model No: 3390 Title Drawring No:
