Customer : M-490 Plus Rev,Date:
No. Part No. Part name & Description Q’ty Ref.
188 300-024-5Y TRANSFORMER EI-28 (OPT) 1 T201
189 300-136-3W TRANSFORMER LE119-H019 1 CH501
190 310-022-6Z COIL RF CHOKE 10UF CR5K-869538 1 L601
188 300-024-5Y TRANSFORMER EI-28 (OPT) 1 T201
189 300-136-3W TRANSFORMER LE119-H019 1 CH501
190 310-022-6Z COIL RF CHOKE 10UF CR5K-869538 1 L601
191 310-291-2Z COIL AXIAL 6.8UH:TCEC-6R8K 2 L1.306
192 310-296-7Z COIL SPRING 6X0.8X5.5T:R 1 L308
193 310-297-8Z COIL SPRING 2.5X0.8X7T:R 1 L304
194 310-301-8 COIL CHOKE 6UH BOBBIN CORE 1 L201
195 310-347-0Z COIL SPRING 5.2X0.7X7T:R 1 L313
196 310-407-1 COIL SPRING 5X0.6X13.5T:R 1 L307
197 310-621-7Z COIL AXIAL 1.5UH:CESS-1R5K 1 L100
198 310-751-1 COIL SPRING 4X0.5X7T:R 1 L311
199 310-811-2 COIL SPRING 3.4X0.55X8.5T:R 1 L312
200 320-276-2Y COIL IFT DET R4251-AHK7-854462 1 L104
201 320-318-7Z COIL IFT Z73C-359 2 L301.302
202 320-576-3U COIL IFT 10.7MHZ MAX RX 1 L103
203 320-577-4 COIL IFT 37MHZ TX 1 L303
204 320-580-6X COIL IFT 16.5MHZ 82PF COIL VCO 1 L501
205 320-584-0Z COIL IFT R4251-AHK7-854461 1 L106
206 320-585-1Z COIL IFT 27MHZ Z073I-1 1 L101
207 321-095-2 COIL IFT 27MHZ RX (7RC) 1 L102
208 509-110 6.5T SPRING COIL ASS6.5T3.4X.55:M9D3.7X6 1 L314
209 310-809-1 COIL SPRING 3.4X0.55X6.5T:R 1
210 321-053-2 CORE 1108-KA-058 M9DTH3.7X6 1
211 594-083 CB BPF MODULE ALAN-78 PLUS 1
212 131-027-0Y CHIP CERAMIC 100PF GRM40 COG101J 50V PT 2 C400.409
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 46 / 61
Model No: 3390 Title Drawring No:
