Customer : M-490 Plus Rev,Date:
No. Part No. Part name & Description Q’ty Ref.
213 131-529-7Y CHIP CERAMIC 150PF GRM40 COG151J 50V PT 3 C402.404.406
214 133-306-2Y CHIP CERAMIC 33PF GRM40 COG330J 50V PT 1 C408
215 134-722-1Y CHIP CERAMIC 47PF GRM40 COG470J 50V PT 3 C403.405.407
216 310-621-7Z COIL AXIAL 1.5UH:CESS-1R5K 1 L404
217 310-823-3 CORE SPRING ASS'Y5.5TX0.45XM5E(R)X2.3 3 L401.402.403
213 131-529-7Y CHIP CERAMIC 150PF GRM40 COG151J 50V PT 3 C402.404.406
214 133-306-2Y CHIP CERAMIC 33PF GRM40 COG330J 50V PT 1 C408
215 134-722-1Y CHIP CERAMIC 47PF GRM40 COG470J 50V PT 3 C403.405.407
216 310-621-7Z COIL AXIAL 1.5UH:CESS-1R5K 1 L404
217 310-823-3 CORE SPRING ASS'y 5.5TX0.45XM5E(R)X2.3 3 L401.402.403
218 411-985 P.C.B SUB 25.5 X9 X1.2 FR4 1/1 1
219 533-90P-A PACKING ASS'Y 1
220 504-629 MOLEX RECEPTACLE ASS900MM 1
221 533-90S-PM SUB PCB MANUAL ASS'Y 1
222 533-90W-JMA WIRE JACK MIC ASS'Y 1
223 427-005-0 WIRE 1007 AWG 24 (1/0.51) YEL 0.17 MIC4 --- MP MIC4
0.5:0.5
224 427-006-1 WIRE 1007 AWG 24 (1/0.51) GRN 0.18 MIC3 --- MP MIC3
0.5:0.5
225 427-007-2 WIRE 1007 AWG 24 (1/0.51) BLU 0.17 MIC5 --- MP MIC5
0.5:0.5
226 427-008-3 WIRE 1007 AWG 24 (1/0.51) VIO 0.16 MIC2 --- MP MIC2
0.5:0.5
227 427-010-4 WIRE 1007 AWG 24(1/0.51) WHT 0.12 MIC1 --- MP MIC1
0.5:0.5
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 47 / 61
