Intek M-490 Plus - Page 46

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
No. Part No. Part name & Description Q’ty Ref.
228 533-90W-MA WIRE MIC ASS'Y 1
229 427-023-6 WIRE 1007 AWG 24(11/0.16) RED 0.06 SW --- PCB MIC
0.5:0.5
230 427-025-8 WIRE 1007 AWG 24(11/0.16) YEL 0.06 SW --- MIC(+)
0.5:0.5
231 427-026-9 WIRE 1007 AWG 24 (11/0.16) GRN 0.08 SW --- MIC(-)
0.5:0.5
232 533-90W-MP WIRE MAIN PCB ASS'Y 1
233 427-045-6 WIRE 1007 AWG 26(7/0.16) YEL 0.19 SPK(+) --- MP SPK(+)
0.5:0.5
234 427-046-7 WIRE 1007 AWG 26(7/0.16) GRN 0.19 SPK(-) --- MP SPK(-)
0.5:0.5
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 48 / 61
