Intek M-490 Plus - Page 53

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
IC9 24LLC02A
PIN TX RX PIN TX RX
1 0 0 5 0 0
2 0 0 6 4.3 4.3
3 0 0 7 0 0
4 0 0 8 4.3 4.3
IC2 KIA324
PIN TX RX PIN TX RX
1 0 0 8 0 3.8
2 3.2 3.2 9 0 3.7
3 3.2 3.2 10 0 3.7
4 7.9 7.9 11 0 0
5 3.8 3.8 12 0 0
6 3.8 3.8 13 0 3.7
7 3.8 3.8 14 0 0
IC1 KIA7042F
PIN TX RX PIN TX RX
1 5 5 3 4.4 4.4
2 0 0 - - -
IC602 MC14066BDR2
PIN TX RX PIN TX RX
1 0 0 8 0.3 0.3
2 0.8 0.8 9 0.5 0.5
3 0.8 0.8 10 0.3 0.3
4 0.8 0.8 11 0.2 0.2
5 4.3 4.3 12 4.3 4.3
6 0 0 13 0 0
7 0 0 14 5 5
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 55 / 61
