Intek M-490 Plus - SEMICONDUCTOR LEAD IDENTIFICATION AND IC INTERNAL CONNECTIONS; IC101 Lead Identification; IC102 Lead Identification; IC9 Lead Identification

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
SEMICONDUCTOR LEAD IDENTIFICATION
AND IC INTERNAL CONNECTIONS
INTERATED CIRCUITS
IC101 : S3P8249XZZ-TWR9
IC102 : TK14489
IC9 : 24LLC02
8 PIN
IC104 : KIA7217A
DIODES
1N4004 .1N60 .1N5232
1N5404 .1N5237
KDV251
TRANSISTORS
KTK211 KRC101S, KRC110,
KTC3876, KTC3880
KTC3875,3880
KRC101~104
2SC2314
2SC2078,KTB1367
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 56 / 61
