Intek M-490 Plus - Model M-490 Explode view part list

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
Model M-490 Explode view part list
NO. PART-NO. Part name & Description Q'TY REFERENCE-NO Remark
1. 623-344 (+)TAPPING SCREW(BH)3X8-2S BLK 3
2. 633-082 (+)TAP TITE SCREW BH3X6 BLK 4
3. 633-152 (+)TAP TITE SCREW BH3X4-3S BLK 2
4. 719-072-G UPPER COVER SECC+PVC T=0.75 1
5. 719-073-B COVER BOTTOM SPC+VIN.SHT.T0.75 1
6. 730-015-A HOLDER(SPK) EGI T1 USCOATING 3
7. 891-590 CUSHION 25X25XT5 RUBB.SP0.BLK STI 1
8. 900-708 FELT &77XT0.3 FELT 1
9. 901-794-A FELT 8X45XT0.3 FELT STIC.ALAN4 1
10. 611-095 (+)MACHINE SCREW(FH)2.6X5 ZN-PLAT 4
11. 724-005 LCD BRACKET SPTE T0.3 1
12. 733-065 HOLDER LCD ABS WHITE 1
13. 796-167 PLATE BACK PC T0.5 YELLOW 56.8 X 21 1
14. 801-819 E.S.C ABS 94HB BLACK 1
15. 814-550 WINDOW ACRYL 1
16. 826-143 KNOB VOL ABS 94HB BLK 4
17. 826-144 KNOB CH ABS 94HB BLK 1
18. 896-425 KEY PAD SILICONE RUBBER CLEAR 1
19. 896-436 EMG KEY SILICONE RUBBER RED / BLU 1
20. 907-146 DOUBLE TAPE 3M TAPE T0.16 1
21. 853-105 BUSHING NYLON66+GLASS 1
22. 401-179-B P.C.B MAIN 153.5 X 167.7 X 1.6T FR4 1/1 1
23. 504-892 MOLEX PLUG ASS'Y 1
24. 613-305 (+)MACHINE SCREW(BH)3X8 ZN-PLAT 1 TR MTG:1
25. 613-332 (+)MACHINE SCREW(BH)3X10 ZN-PLAT 3
26. 621-420 (+)TAPPING SCREW(PH)2.6X8-2S ZN-PLAT 2
27. 623-265 (+)TAPPING SCREW(BH)3X6-2S ZN-PLAT 6
28. 651-024 NUT SS41 M3-1S ZN-PLAT 4
29. 660-590 WASHER FIBER 7&X3.2& 1T RED 2
30. 662-305 WASHER (SPRING) M3 ZN-PLAT 4
31. 702-426-E MAIN BODY EGI T1.0 US COATING 1
32. 732-560 HOLDER(ANT MTG) SPTE T0.3 1
33. 750-766 CORD STOPPER PP 1
34. 760-704 HEAT SINK(IC MTG) ALP 30X18XT2 1
35. 853-105 BUSHING NYLON66+GLASS 1 TR MTG
36. 771-850 SHIELD PLATE SPTE T0.5 1
37. 772-238 SHIELD HOUSING SPTE T0.3 1
38. 95B-009-D NAME LABEL POLYESTER 40 X 27 1
39. 420-113-6 SPEAKER 8 OHM 3.0W 77MM P-302RM-A 1
40. 202-066-2 TRANSISTOR KTB1367 1 Q214
41. 204-010-1 TRANSISTOR 2SC2078(E) 1 Q304
42. 204-016-7 TRANSISTOR 2SC2314(E) 1 Q303
43. 222-006-4 I.C KIA7217AP 1 IC103
44. 411-271-B P.C.B ROTARY 17 X 14 X 1.6T FR4 1/1 1
45. 411-838-B P.C.B LCD 149 X 46 X 1.6T FR4 1/1 1
46. 411-387-C P.C.B VOLUME 82 X 29 X 1.6T XPC-94HB 1
47. 420-705-1Z JACK DC TC38-078-01 2 J1.101
48. 420-726-3X JACK MINIATURE FJ-2506 2.5MM 1 J102
49. 421-046-7 CONNECTOR CH-239(A) SW-1229 1 J103(ANT)
50. 421-595-6 CONNECTOR SCN-16-6(BR):SW-1610 1 J105(MIC JACK)
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 59 / 61
