Intek M-490 Plus - Page 58

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
51. 429-078-6B FLAT WIRE 07P 88MM 2.5PITCH 2
52. 429-266-9Z FLAT CABLE 03P 80MM 2.5PITCH (HH-35) 1
53. 430-049-8Y SW ROTARY YPS210120SK 1 SW105
54. 440-020-4 MICA 0.1T:15X13 MICA FOR TR 1
55. 450-609-0 VR 50KA:K161110-5M1112 PCB TYPE 2 VR102.108
56. 450-621-0Y VR (B50K) RV16A-20-25K-B54-3 2 VR1.2
57. 251-052-9Z LED LAMP LTL-16KE RED 5V 100MW 1 LED3
58. 251-162-5Z LED LAMP LTL-81HGK 5 B1.2.3.4.5
59. 251-224-8Z PILOT LAMP 60MA 3& 14V 3 B101.102.103
60. 251-286-4Z LAMP LED L-115 VEGW 1 LED1
61. 252-327-0 LCD DISPLAY IS06618P 1 LCD1
62. 431-162-1Z SW SLIDE SKS-22021T 2 SW9.11
63. 436-059-7Z SW TACT TM115AP 10 SW1.2.3.4.5.6.7.8.10.12
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 60 / 61
