Intel Desktop Board DH67CL Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Two USB 3.0 ports are implemented with stacked back panel connectors (blue)
• Fourteen USB 2.0 ports:
― Six ports are implemented with stacked back panel connectors (black)
― Eight front panel ports implemented through four internal headers
• Two SATA 6.0 Gb/s interfaces through Intel H67 Express Chipset with Intel
®
Rapid Storage Technology RAID support (blue)
• Four Serial ATA (SATA) 3.0 Gb/s interfaces through Intel H67 Express Chipset
with Intel Rapid Storage Technology RAID support:
― Two internal SATA ports (black)
― One internal eSATA port (red)
― One back panel eSATA port (red)
Expansion
Capabilities
• One PCI Express 2.0 x16 add-in card connector
• Two PCI Express 2.0 x1 add-in card connectors
• Three Conventional PCI bus connectors
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express* Revision 2.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, Consumer Infrared (CIR), and
USB ports
LAN Support
Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel
®
82579V Gigabit
Ethernet Controller
Legacy I/O Control Nuvoton W83677HG-i I/O controller for CIR and hardware management support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control
