Intel Desktop Board DH67CL Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Descript
ion
A PCI Conventional bus add-in card connector
B PCI Conventional bus add-in card connector
C PCI Conventional bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x1 bus add-in card connector
F PCI Express x16 bus add-in card connector
G Back panel connectors
H Processor core power connector (2 x 2)
I Rear chassis fan header
J LGA1155 processor socket
K Processor fan header
L DIMM 3 (Channel A DIMM 0)
M DIMM 1 (Channel A DIMM 1)
N DIMM 4 (Channel B DIMM 0)
O DIMM 2 (Channel B DIMM 1)
P Front chassis fan header
Q Chassis intrusion header
R Low Pin Count (LPC) Debug header
S Consumer IR receiver (input) header
T Consumer IR emitter (output) header
U Main power connector (2 x 12)
V Battery
W Piezoelectric speaker
X SATA connectors (5)
Y Alternate front panel power LED header
Z Front panel header
AA BIOS Setup configuration jumper block
BB Standby power LED
CC Front panel USB 2.0 headers (4)
DD Intel P67 Express Chipset
EE S/PDIF out header
FF Front panel audio header
