Intel BLKDH67CL - Component-Side Connectors and Headers Shown in Figure 10

Intel Desktop Board DH67CL Technical Product Specification
44
Table 12 lists the component-side connectors and headers identified in Figure 10.
Table 12. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A PCI Conventional bus add-in card connector
B PCI Conventional bus add-in card connector
C PCI Conventional bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x1 bus add-in card connector
F PCI Express x16 bus add-in card connector
G Processor core power connector (2 x 2)
H Rear chassis fan header
I Processor fan header
J Front chassis fan header
K LPC Debug header
L Chassis intrusion header
M Consumer IR emitter (output) header
N Consumer IR receiver (input) header
O Main power connector (2 X 12)
P SATA connectors
Q Alternate front panel power LED header
R Front panel header
S Front panel USB 2.0 header
T Front panel USB 2.0 header
U Front panel USB 2.0 header
V Front panel USB 2.0 header
W S/PDIF out header
X Front panel audio header
