Intel Desktop Board DG43GT Product Guide
12
Table 2. Intel Desktop Board DG43GT Components
Label Description
A Front panel audio header
B PCI bus connector
C IEEE 1394a header
D PCI Express x1 connector
E PCI Express x16 connector
F Battery
G PCI Express x1 connector
H Back panel connectors
I 12 V processor core voltage connector (2 x 2 pin)
J Rear chassis fan header (3-pin)
K Processor socket
L Processor fan header (4-pin)
M DDR2 DIMM 0 sockets
N Front chassis fan header (3-pin)
O DDR2 DIMM 1 sockets
P Serial header
Q Parallel port header
R Main power connector (2 x 12 pin)
S Front panel header
T Serial ATA connectors (4)
U Alternate front panel power LED header
V High-speed USB 2.0 headers (3)
W Parallel ATA connector
X Clear CMOS jumper block
Y Chassis intrusion header
Z BIOS configuration jumper block
AA Speaker
BB S/PDIF header
