Intel Desktop Board DX58SO Product Guide
24
Figure 5. Onboard Power Button
Onboard VR and CPU LEDs
The Desktop Board contains the following two LEDs (see Figure 6) that indicate the
status of the board’s voltage regulation circuitry and the processor:
• The CPU LED (Figure 6, A) indicates an elevated temperature on
the processor that
could affect performance.
• The VR LED (Figure 6, B) indicates an elevated temperature in the processor
voltage regulator circuit that
could affect performance.
