Land Listing and Signal Descriptions
42 Datasheet
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
A3# L5 Source Synch Input/Output
A4# P6 Source Synch Input/Output
A5# M5 Source Synch Input/Output
A6# L4 Source Synch Input/Output
A7# M4 Source Synch Input/Output
A8# R4 Source Synch Input/Output
A9# T5 Source Synch Input/Output
A10# U6 Source Synch Input/Output
A11# T4 Source Synch Input/Output
A12# U5 Source Synch Input/Output
A13# U4 Source Synch Input/Output
A14# V5 Source Synch Input/Output
A15# V4 Source Synch Input/Output
A16# W5 Source Synch Input/Output
A17# AB6 Source Synch Input/Output
A18# W6 Source Synch Input/Output
A19# Y6 Source Synch Input/Output
A20# Y4 Source Synch Input/Output
A21# AA4 Source Synch Input/Output
A22# AD6 Source Synch Input/Output
A23# AA5 Source Synch Input/Output
A24# AB5 Source Synch Input/Output
A25# AC5 Source Synch Input/Output
A26# AB4 Source Synch Input/Output
A27# AF5 Source Synch Input/Output
A28# AF4 Source Synch Input/Output
A29# AG6 Source Synch Input/Output
A30# AG4 Source Synch Input/Output
A31# AG5 Source Synch Input/Output
A32# AH4 Source Synch Input/Output
A33# AH5 Source Synch Input/Output
A34# AJ5 Source Synch Input/Output
A35# AJ6 Source Synch Input/Output
A20M# K3 Asynch CMOS Input
ADS# D2 Common Clock Input/Output
ADSTB0# R6 Source Synch Input/Output
ADSTB1# AD5 Source Synch Input/Output
BCLK0 F28 Clock Input
BCLK1 G28 Clock Input
BNR# C2 Common Clock Input/Output
BPM0# AJ2 Common Clock Input/Output
BPM1# AJ1 Common Clock Input/Output
BPM2# AD2 Common Clock Input/Output
BPM3# AG2 Common Clock Input/Output
BPM4# AF2 Common Clock Input/Output
BPM5# AG3 Common Clock Input/Output
BPMb0# G1 Common Clock Input/Output
BPMb1# C9 Common Clock Input/Output
BPMb2# G4 Common Clock Input/Output
BPMb3# G3 Common Clock Input/Output
BPRI# G8 Common Clock Input
BR0# F3 Common Clock Input/Output
BSEL0 G29 Power/Other Output
BSEL1 H30 Power/Other Output
BSEL2 G30 Power/Other Output
COMP0 A13 Power/Other Input
COMP1 T1 Power/Other Input
COMP2 G2 Power/Other Input
COMP3 R1 Power/Other Input
COMP8 B13 Power/Other Input
D0# B4 Source Synch Input/Output
D1# C5 Source Synch Input/Output
D2# A4 Source Synch Input/Output
D3# C6 Source Synch Input/Output
D4# A5 Source Synch Input/Output
D5# B6 Source Synch Input/Output
D6# B7 Source Synch Input/Output
D7# A7 Source Synch Input/Output
D8# A10 Source Synch Input/Output
D9# A11 Source Synch Input/Output
D10# B10 Source Synch Input/Output
D11# C11 Source Synch Input/Output
D12# D8 Source Synch Input/Output
D13# B12 Source Synch Input/Output
D14# C12 Source Synch Input/Output
D15# D11 Source Synch Input/Output
D16# G9 Source Synch Input/Output
D17# F8 Source Synch Input/Output
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
