Land Listing and Signal Descriptions
Datasheet 43
D18# F9 Source Synch Input/Output
D19# E9 Source Synch Input/Output
D20# D7 Source Synch Input/Output
D21# E10 Source Synch Input/Output
D22# D10 Source Synch Input/Output
D23# F11 Source Synch Input/Output
D24# F12 Source Synch Input/Output
D25# D13 Source Synch Input/Output
D26# E13 Source Synch Input/Output
D27# G13 Source Synch Input/Output
D28# F14 Source Synch Input/Output
D29# G14 Source Synch Input/Output
D30# F15 Source Synch Input/Output
D31# G15 Source Synch Input/Output
D32# G16 Source Synch Input/Output
D33# E15 Source Synch Input/Output
D34# E16 Source Synch Input/Output
D35# G18 Source Synch Input/Output
D36# G17 Source Synch Input/Output
D37# F17 Source Synch Input/Output
D38# F18 Source Synch Input/Output
D39# E18 Source Synch Input/Output
D40# E19 Source Synch Input/Output
D41# F20 Source Synch Input/Output
D42# E21 Source Synch Input/Output
D43# F21 Source Synch Input/Output
D44# G21 Source Synch Input/Output
D45# E22 Source Synch Input/Output
D46# D22 Source Synch Input/Output
D47# G22 Source Synch Input/Output
D48# D20 Source Synch Input/Output
D49# D17 Source Synch Input/Output
D50# A14 Source Synch Input/Output
D51# C15 Source Synch Input/Output
D52# C14 Source Synch Input/Output
D53# B15 Source Synch Input/Output
D54# C18 Source Synch Input/Output
D55# B16 Source Synch Input/Output
D56# A17 Source Synch Input/Output
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
D57# B18 Source Synch Input/Output
D58# C21 Source Synch Input/Output
D59# B21 Source Synch Input/Output
D60# B19 Source Synch Input/Output
D61# A19 Source Synch Input/Output
D62# A22 Source Synch Input/Output
D63# B22 Source Synch Input/Output
DBI0# A8 Source Synch Input/Output
DBI1# G11 Source Synch Input/Output
DBI2# D19 Source Synch Input/Output
DBI3# C20 Source Synch Input/Output
DBR# AC2 Power/Other Output
DBSY# B2 Common Clock Input/Output
DEFER# G7 Common Clock Input
DRDY# C1 Common Clock Input/Output
DSTBN0# C8 Source Synch Input/Output
DSTBN1# G12 Source Synch Input/Output
DSTBN2# G20 Source Synch Input/Output
DSTBN3# A16 Source Synch Input/Output
DSTBP0# B9 Source Synch Input/Output
DSTBP1# E12 Source Synch Input/Output
DSTBP2# G19 Source Synch Input/Output
DSTBP3# C17 Source Synch Input/Output
FC0 Y1 Power/Other
FC3 J2 Power/Other
FC10 E24 Power/Other
FC15 H29 Power/Other
FC17 Y3 Power/Other
FC18 AE3 Power/Other
FC20 E5 Power/Other
FC21 F6 Power/Other
FC22 J3 Power/Other
FC23 A24 Power/Other
FC24 AK1 Power/Other
FC25 AL1 Power/Other
FC26 E29 Power/Other
FC29 U2 Power/Other
FC30 U3 Power/Other
FC31 J16 Power/Other
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
