Land Listing and Signal Descriptions
56 Datasheet
M30 VCC Power/Other
N1 PWRGOOD Power/Other Input
N2 IGNNE# Asynch CMOS Input
N3 VSS Power/Other
N4 RESERVED
N5 RESERVED
N6 VSS Power/Other
N7 VSS Power/Other
N8 VCC Power/Other
N23 VCC Power/Other
N24 VCC Power/Other
N25 VCC Power/Other
N26 VCC Power/Other
N27 VCC Power/Other
N28 VCC Power/Other
N29 VCC Power/Other
N30 VCC Power/Other
P1 TESTHI11 Power/Other Input
P2 SMI# Asynch CMOS Input
P3 INIT# Asynch CMOS Input
P4 VSS Power/Other
P5 RESERVED
P6 A04# Source Synch Input/Output
P7 VSS Power/Other
P8 VCC Power/Other
P23 VSS Power/Other
P24 VSS Power/Other
P25 VSS Power/Other
P26 VSS Power/Other
P27 VSS Power/Other
P28 VSS Power/Other
P29 VSS Power/Other
P30 VSS Power/Other
R1 COMP3 Power/Other Input
R2 VSS Power/Other
R3 FERR#/PBE# Asynch CMOS Output
R4 A08# Source Synch Input/Output
R5 VSS Power/Other
R6 ADSTB0# Source Synch Input/Output
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
R7 VSS Power/Other
R8 VCC Power/Other
R23 VSS Power/Other
R24 VSS Power/Other
R25 VSS Power/Other
R26 VSS Power/Other
R27 VSS Power/Other
R28 VSS Power/Other
R29 VSS Power/Other
R30 VSS Power/Other
T1 COMP1 Power/Other Input
T2 FC4 Power/Other
T3 VSS Power/Other
T4 A11# Source Synch Input/Output
T5 A09# Source Synch Input/Output
T6 VSS Power/Other
T7 VSS Power/Other
T8 VCC Power/Other
T23 VCC Power/Other
T24 VCC Power/Other
T25 VCC Power/Other
T26 VCC Power/Other
T27 VCC Power/Other
T28 VCC Power/Other
T29 VCC Power/Other
T30 VCC Power/Other
U1 TDO_M TAP Output
U2 FC29 Power/Other
U3 FC30 Power/Other
U4 A13# Source Synch Input/Output
U5 A12# Source Synch Input/Output
U6 A10# Source Synch Input/Output
U7 VSS Power/Other
U8 VCC Power/Other
U23 VCC Power/Other
U24 VCC Power/Other
U25 VCC Power/Other
U26 VCC Power/Other
U27 VCC Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
