Land Listing and Signal Descriptions
Datasheet 57
U28 VCC Power/Other
U29 VCC Power/Other
U30 VCC Power/Other
V1 MSID1 Power/Other Output
V2 RESERVED
V3 VSS Power/Other
V4 A15# Source Synch Input/Output
V5 A14# Source Synch Input/Output
V6 VSS Power/Other
V7 VSS Power/Other
V8 VCC Power/Other
V23 VSS Power/Other
V24 VSS Power/Other
V25 VSS Power/Other
V26 VSS Power/Other
V27 VSS Power/Other
V28 VSS Power/Other
V29 VSS Power/Other
V30 VSS Power/Other
W1 MSID0 Power/Other Output
W2 TDI_M Power/Other Input
W3 TESTHI1 Power/Other Input
W4 VSS Power/Other
W5 A16# Source Synch Input/Output
W6 A18# Source Synch Input/Output
W7 VSS Power/Other
W8 VCC Power/Other
W23 VCC Power/Other
W24 VCC Power/Other
W25 VCC Power/Other
W26 VCC Power/Other
W27 VCC Power/Other
W28 VCC Power/Other
W29 VCC Power/Other
W30 VCC Power/Other
Y1 FC0 Power/Other
Y2 VSS Power/Other
Y3 FC17 Power/Other
Y4 A20# Source Synch Input/Output
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
Y5 VSS Power/Other
Y6 A19# Source Synch Input/Output
Y7 VSS Power/Other
Y8 VCC Power/Other
Y23 VCC Power/Other
Y24 VCC Power/Other
Y25 VCC Power/Other
Y26 VCC Power/Other
Y27 VCC Power/Other
Y28 VCC Power/Other
Y29 VCC Power/Other
Y30 VCC Power/Other
AA1
VTT_OUT_
RIGHT
Power/Other Output
AA2 FC39 Power/Other
AA3 VSS Power/Other
AA4 A21# Source Synch Input/Output
AA5 A23# Source Synch Input/Output
AA6 VSS Power/Other
AA7 VSS Power/Other
AA8 VCC Power/Other
AA23 VSS Power/Other
AA24 VSS Power/Other
AA25 VSS Power/Other
AA26 VSS Power/Other
AA27 VSS Power/Other
AA28 VSS Power/Other
AA29 VSS Power/Other
AA30 VSS Power/Other
AB1 VSS Power/Other
AB2 IERR# Asynch CMOS Output
AB3 FC37 Power/Other
AB4 A26# Source Synch Input/Output
AB5 A24# Source Synch Input/Output
AB6 A17# Source Synch Input/Output
AB7 VSS Power/Other
AB8 VCC Power/Other
AB23 VSS Power/Other
AB24 VSS Power/Other
AB25 VSS Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
