Identification Information
Specification Update 29
S-Spec
Core
Stepping
L2 Cache
Size (bytes)
CPUID Speed Core/Bus Package and Revision Notes
SL6WS D1 512K 0F29h 2.60GHz/800MHz 31.0 mm FC rev 1.0 1, 5, 11,
16
SL6WT D1 512K 0F29h 2.80GHz/800MHz 31.0 mm FC rev 1.0 1, 5, 11,
16
SL6Z3 M0 512K 0F25h 2.40GHz/800MHz 31.0 mm FC rev 1.0 1, 5, 11,
16,18,20
SL6Z5 M0 512K 0F25h 2.80GHz/800MHz 31.0 mm FC rev 1.0 1, 5, 11,
16,18,20
SL7AA M0 512K
2M (L3)
0F25h 3.20GHz/800MHz 31.0 mm FC rev 1.0 2, 11, 16,
21, 22
SL7CH M0 512K
2M (L3)
0F25h 3.40GHz/800MHz 31.0 mm FC rev 1.0 2, 11, 16,
21, 22
SL793 D1 512K 0F29h 3.40GHz/800MHz 31.0 mm FC rev 1.0 5, 11, 16
SL7EY D1 512K 0F29h 2.80 GHz/400MHz 31.0 mm FC rev 1.0 5, 16
SL7GD M0
512K
2M (L3)
0F25h 3.40GHz/800MHz
775-land FC-LGA4
37.5 x 37.5 mm Rev
01
11, 16, 21,
22, 24
SL7NF M0
512k
2M (L3)
0F25h 3.46GHz/1066MHz
775-land FC-LGA4
37.5 x 37.5 mm Rev
01
2, 11, 21,
22, 24
SL79B M0 512k 0F25h 2.4GHz/533MHz 31.0 mm FC rev 1.0 1
SL7BK M0 512k 0F25h 3.0GHz/800MHz 31.0 mm FC rev 1.0 1
NOTES:
1. This is a boxed Intel
®
Pentium
®
4 processor with an unattached fan heat sink.
2. These are tray processors, but some are also offered as boxed processors with an
unattached fan heatsink.
3. These processors are Pentium 4 processors in the 423-pin package.
4. These processors are Pentium 4 processors in the 478-pin package.
5. These processors are Pentium 4 processors with 512-KB L2 cache on 0.13 micron
process.
6. These parts have some specifications that differ from those in the Intel
®
Pentium
®
4
Processor in the 478-pin Package datasheet. The specifications that are different from
the datasheet are: Vmax = 1.665 V, Vmin = 1.570 V, Icc_max = 46.1 A, TDP =
62.9 W, Tcase = 71 °C, Isgnt = 15.8 A.
7. These parts have some specifications that differ from those in the Intel
®
Pentium
®
4
Processor in the 478-pin Package datasheet. The specifications that are different from
the datasheet are: Vmax = 1.655 V, Vmin = 1.560 V, Icc_max = 50.2 A, TDP =
67.7 W, Tcase = 73 °C, Isgnt = 16.1 A.
8. These parts have some specifications that differ from those in the Intel
®
Pentium
®
4
Processor with 512-KB L2 Cache on 0.13 Micron Process datasheet. The specifications
that are different from the datasheet are: Vmax= 1.425 V, Vmin=1.355 V, Icc_max =
38.8 A, TDP= 46.8W, Tcase= 66 °C, Isgnt=17.0 A.
9. These parts have some specifications that differ from those in the Intel
®
Pentium
®
4
Processor with 512-KB L2 Cache on 0.13 Micron Process datasheet. The specifications
that are different from the datasheet are: Vmax= 1.420 V, Vmin=1.350 V, Icc_max =
41.6 A, TDP= 49.6 W, Tcase= 67 °C, Isgnt=17.1 A.
10. These processors incorrectly return a Brand ID of 0Ah instead of the expected Brand ID
of 09h. The Brand ID corresponds to bits [7:0] of the EBX register after the CPUID
instruction is executed with a 1 in the EAX register.
