Intel Celeron 1047UE/847 User Manual

7
Jumper
Jumper Name Description
JP1 INVERTER VCC 12V/5V Select 3-Pin Block
JP3 LVDS PVCC 5V/3.3V Select 3-Pin Block
JBAT1 CMOS RAM Clear Function Setting 3-Pin Block
JCOMP1 COM1 Header Pin9 Function Select 6-Pin Block
JCOMP2 COM2 Header Pin9 Function Select 6-Pin Block
JCOMP3 COM3 Header Pin9 Function Select 6-Pin Block
JCOMP4 COM4 Header Pin9 Function Select 6-Pin Block
COPEN1 Case Open Message Display Function 2-pin Block
Connectors
Connector Name
DC12V1 DC 12V Power–in Connector
USB1/2 USB 2.0 Port Connectors
LAN1/2 RJ-45 LAN Port Connectors
DVI1 DVI-I Port Connector
AUDIO2 Audio Line Out Connector
SATA1 SATAIII Port Connector
PWOUT1 SATA Power out Connector
CPUFAN1 CPUFAN Connector
INVERTER LVDS Inverter Connector
Headers
Header Name Description
AUDIO1
Front Panel Audio Header 9-pin block
SPDIF
SPDIF Out
Header 2-pin block
COM1/2/3/4
Serial Port
Headers
9-pin block
GPIO1
GPIO
Header
10-pin block
USB3 USB 2.0 header 9-pin block
