SM_BUS header x1
z
Front panel header x1
z
CIR header x1
z
LANLED header x2
z
LVDS header x1
1-3 Layout Diagram
Rear IO Panel Diagram:
DC12V
Power-in
Connector
Line-Out Port
USB 2.0 Ports
RJ-45 LAN Ports
DVI-I Port
USB 2.0 Ports
