Internal Diagram-Front Side:
LANLED Headers
SATA III Port
CPUFAN Heade
r
Front Panel Heade
r
SODIMM Slot
Reset Button
Power Switch Button
DC 12V Power-in
Connector
USB 2.0 Ports
DVI-I Port
CFast Slot
SM_BUS
Header
INVERTER
LVDS Header
Mini-PCIE/mSATA Slot
USB 2.0 Ports
Line-Out Port
RJ-45 LAN Port
RJ-45 LAN Port
Serial port Header
(COM1/2/3/4)
GPIO Header
USB 2.0 Heade
r
USB 2.0 Heade
r
Front Panel Audio Header
SATA
Power Connector
CIR Header
SPDIF Header
