14
(3)SATA Power Connector (4-pin): PWOUT1
Pin 1
+12V
GND
+5V
GND
(4) CPUFAN1 (4-pin): CPUFAN Connector
CPUFAN1
GND
Pin1
VCC
Fan Clock
Control
