(10)LAN1_LED/LAN2_LED (2-pin): LANLED Headers
LAN1_LED
Pin1
LED+
LED-
Pin1
LAN2_LED
LED+
LED-
(11) LVDS1 (30-pin): 24-bit Single Channel LVDS Header
Pin 1
Pin2
Pin 29
Pin 30
