14
4. LED Status Indicator – the LED Status Indicator displays the operating status of your Intel-
powered Classmate PC-Convertible. When a certain function is enabled, the LED will light up.
The following describes each indicator:
Blue light indicates the numeric keypad is activated.
Blue light indicates the cap-lock is activated.
Blue light indicates the device is reading/writing data.
Blue light indicates the WLAN module is active.
The battery LED reflects according to the following status:
Blue light indicates the battery is fully charged and the AC Adapter is plugged in.
Orange light indicates the battery power is low.
5. Built-In Microphone – the microphone is used when you are having an audio/video conference
with another party, or if you are making a voice recording on software.
6. Power LED Status Indicator – the blue light indicates that the system is ON.
7. Power/Suspend Button – press momentarily to turn on the system, and then press the button
again to return for the suspend mode.
Note: Press this button once to enable and pop-up the webcam application in full-screen mode.
Under the webcam application, press this button once to take a picture.
8. Touchpad – the touchpad is a built-in pointing device with functions similar to a mouse.
9. Touchpad Buttons – this works similar to the two buttons on a desktop mouse.
