54 Mobile Intel
®
945GM Express Chipset
Development Kit User’s Manual
Hardware Reference
44 N/C GND
45 GND N/C
46 GND N/C
47 N/C GND
48 N/C MEC_Enable
49 GND GND
End of x8 Connector
50 Reserved SDVOC_CLK+
51 GND SDVOC_CLK-
52 N/C GND
53 N/C GND
54 GND SDVOC_Blue+
55 GND SDVOC_Blue-
56 N/C GND
57 N/C GND
58 GND SDVOC_Green+
59 GND SDVOC_Green-
60 SDVOC_Int+ GND
61 SDVOC_Int- GND
62 GND SDVOC_Red+
63 GND SDVOC_Red-
64 N/C GND
65 N/C GND
66 GND SDVOB_Clk+
67 GND SDVOB_Clk-
68 N/C GND
69 N/C GND
70 GND SDVOB_Blue+
71 GND SDVOB_Blue-
72 SDVO_Stall+ GND
73 SDVO_Stall- GND
74 GND SDVOB_Green+
75 GND SDVOB_Green-
76 SDVOB_Int+ GND
77 SDVOB_Int- GND
78 GND SDVOB_Red+
79 GND SDVOB_Red-
Table 13. MEC Slot (J6C1) (Sheet 3 of 4)
Pin Number A B
