Intel Desktop Board D201GLY2 Product Guide
12
Table 2. Desktop Boards D201GLY2 Components
Label Description
A PCI bus add-in card connector
B Hi-speed USB 2.0 headers
C Front panel audio header
D Back panel connectors
E Rear fan (3-pin) header
F 12 V processor core voltage connector (2 x 2)
G Main power connector (2 x 10)
H Processor
I DDR 2 DIMM connector
J IDE connector
K Serial ATA connectors
L Front panel header
M Battery
N BIOS configuration jumper
Related Links:
Go to the following links for more information about:
• Desktop Board D201GLY2
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
