Intel D53427RKE - Board Layout (Bottom); Major Board Components (Bottom)

Product Description
15
1.1.3 Board Layout (Bottom)
Figure 2 shows the location of the major components on the bottom-side of Intel NUC
Board D53427RKE.
Figure 2. Major Board Components (Bottom)
