Intel D53427RKE - Dual-Port Front Panel USB 2.0 Header

Intel NUC D53427RKE Technical Product Specification
48
Table 12. Dual-Port Front Panel USB 2.0 Header
Pin Signal Name Pin Signal Name
1 +5 V DC 2 +5 V DC
3 D− 4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 No Connect
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One PCI Express Half-Mini Card
• One PCI Express Full-Mini Card
