Intel D53427RKE User Manual

Technical Reference
47
Table 11. PCI Express Full-/Half-Mini Card Connector (continued)
Pin Signal Name Additional Signal Name
39 +3.3 V aux
40 GND
41 +3.3 V aux
42 LED_WWAN#
43 GND (mSATA) NC
44 LED_WLAN#
45 Reserved (Intel AMT) C-Link_CLK*
46 LED_WPAN#
47 Reserved (Intel AMT) C-Link_DAT*
48 +1.5V
49 Reserved (Intel AMT) C-Link_RST*
50 GND
51 Reserved (mSATA) mSATA SEL
52 +3.3 V aux
NOTE
The mSATA signals are routed only to the PCIe full-mini card connector and not to
the half-mini card connector. These signals are required to support mSATA
modules.
NOTE
The Intel AMT C-Link signals are routed only to the PCIe half-mini card connector
and not to the full-mini card connector. These signals are required to support Intel
AMT Wake-on-LAN for wireless cards.
