英特尔台式机主板 D945PWM 产品指南
6. 用拇指和食指握住处理器,握持方位如图 10 所示。确保手指对准插座上的切口
(参见图 10 中的 F)。使凹口(参见图 10 中的 G)与插座(参见图 10 中的 H
对齐。垂直向下降低处理器,切勿使处理器在插座上倾斜或滑动。
OM19105
G
G
F
H
F
H
10. 安装处理器
7. 向下按压压板(图 11 中的 I),使其闭合,然后扳回并扣紧插座拉杆(图 11 中的 J)。
OM17215
I
J
11. 闭合压板
30
