安装和更换台式机主板组件
其它连接器
图 24 显示了 PCI 附加卡、PCI Express 1x 和软盘驱动器连接器的位置。
OM19114
A
B
E
F
C
D
G
项目 说明
A
PCI 总线附加卡连接器 4
B
PCI 总线附加卡连接器 3
C
PCI Express x1 连接器 2
D
PCI Express x1 连接器 1
E
PCI 总线附加卡连接器 2
F
PCI 总线附加卡连接器 1
G
软盘驱动器连接器
图 24. 台式机主板 D945PWM 上其它连接器位置
45
