Intel Desktop Board DB65AL Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Twelve USB ports:
― Six USB 2.0 ports are implemented with stacked back panel
connectors
― Six USB 2.0 front panel ports are implemented through three
dual-port internal headers
• Six Serial ATA (SATA) interfaces through the Intel B65 Express
Chipset with Intel
®
Rapid Storage Technology RAID support:
― One internal SATA 6 Gb/s port (blue)
― Three internal SATA 3 Gb/s ports (black)
― Two onboard external SATA (eSATA) 3 Gb/s ports (red)
• One serial port header
• One PS/2* back panel connector for mouse/keyboard support
LAN Support
• Intel
®
82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
Legacy I/O
• Nuvoton* W83677HG-i I/O controller for hardware management
and serial port, and PS/2 support
BIOS
• Intel
®
BIOS resident in an SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI Local Bus Specification, Revision 2.2
• Support for PCI Express Base Specification, Revision 2.0
• Suspend to RAM support
• Wake on Conventional PCI, PCI Express, LAN, front panel, serial,
USB ports, and PS/2
Hardware
Monitoring
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers using PWM control
• 4-pin headers for processor, front chassis, and rear chassis fans
• 4-wire and 3-wire (linear) fan speed control support for front and
rear chassis fans
• Support for Platform Environmental Control Interface (PECI)
