Intel Desktop Board DB65AL Product Guide
32
3.
Rotate t
he socket lever to lift the load pl
ate away from the socket (
Figure 8, A).
Make sure that th
e load plate is in the fully open
position (
Figure 8, B) while being
careful not
to damage adjacent componen
ts.
Do not touc
h the socket contacts.
Figure 8. Lift the Lo
ad Plate
