Product Description
25
1.6.1.5 High-bandwidth Digital Content Protection (HDCP)
HDCP is the technology for protecting high definition content against unauthorized
copy or interception between a source (computer, digital set top boxes, etc.) and the
sink (panels, monitor, and TVs). The PCH supports HDCP 1.4 for content protection
over wired displays (HDMI and DisplayPort).
1.6.2 USB
The board supports USB 2.0/3.0 ports. The port arrangement is as follows:
• USB 2.0 ports:
Two front panel ports are implemented through one dual-port internal header
Two ports are implemented with vertical back panel connectors
One port is reserved for the PCI Express Half-Mini Card
One port is reserved for the PCI Express Full-Mini Card
• One front panel USB 3.0 port is implemented through an external connector (blue)
All USB 2.0/3.0 ports are high-speed, full-speed, and low-speed capable.
NOTE
Computer systems that have an unshielded cable attached to a USB port may not meet
FCC Class B requirements, even if no device is attached to the cable. Use a shielded
cable that meets the requirements for full-speed devices.
For information about Refer to
The location of the USB connectors on the back panel Figure 9, page 43
The location of the front panel USB headers Figure 2, page 15
1.6.3 AHCI Mode
The board supports AHCI storage mode via the Intel QS77 Express Chipset.
NOTE
In order to use AHCI mode, AHCI must be enabled in the BIOS. Microsoft Windows 7
and Windows 8 include the necessary AHCI drivers without the need to install separate
AHCI drivers during the operating system installation process, however, it is always
good practice to update the AHCI drivers to the latest available by Intel.
