Intel NUC D53427RKE Technical Product Specification
54
Figure 13. Intel MEBX Reset Header
Table 17. Intel MEBX Reset Header Signals
Pin Function
1 PCH_RTCRST_PULLUP
2 Ground
3 No connection
