安装和更换台式机主板组件
其它连接器和接头连接器
26 显示了本台式机主板上其它连接器和接头连接器的位置。
项目 说明
A PCI 总线连接器 3
B PCI Express x1 连接器 3
C PCI Express x1 连接器 2
D PCI 总线连接器 2
E PCI 总线连接器 1
F PCI Express x1 连接器 1
G
软盘驱动器连接器
H
机箱开启接头连接器
26. 其它连接器和接头连接器位置
51
