Intel DH57DD User Manual

Desktop Board Features
13
Table 2. Intel Desktop Board DH57DD Components
Label Description
A PCI bus connector
B PCI Express 2.0 x1 add-in card connector
C IEEE 1394a header
D IEEE 1394a header
E PCI Express 2.0 x1 add-in card connector
F Battery
G PCI Express 2.0 x16 add-in card connector
H Back panel connectors
I 12 V processor core voltage connector (2 x 2 pin)
J Rear chassis fan header
K Processor socket
L Processor fan header
M DDR3 Channel A DIMM sockets
N DDR3 Channel B DIMM sockets
O Front chassis fan header
P Back panel CIR emitter (output) header
Q Front panel CIR receiver (input) header
R Chassis intrusion header
S Main power connector (2 x 12 pin)
T Speaker
U SATA connectors (5)
V Intel
®
Remote PC Assist Technology (Intel
®
RPAT) header
W Alternate front panel power LED header
X Front panel header
Y Front panel USB 2.0 header
Z Standby power indicator LED
AA Front panel USB 2.0 header
BB Front panel USB 2.0 header
CC Front panel USB 2.0 header
DD BIOS configuration jumper block
EE Intel HD Audio Link header
FF Serial port header
GG S/PDIF header
HH Front panel audio header

Intel DH57DD Specifications

General

Brand	Intel
Model	DH57DD
Category	Motherboard
Language	English
