Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Description
A Conventional PCI bus add-in card connector
B Chassis intrusion header
C S/PDIF header
D PCI Express x1 add-in card connector
E PCI Express x16 bus add-in card connector
F 12 V internal power connector (ATX12V)
G Rear chassis fan header
H Processor fan header
I LPC Debug header
J TPM header
K Main power connector (2 x 12)
L SATA connectors
M Front panel header
N Serial port header
O Front panel USB 2.0 header
P Front panel audio header

Intel DH61WW Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCIe 3.0 x16 Slots	0
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3.0 Gb/s Ports	4
USB 2.0 Ports	10
Audio Channels	6
Video Output	VGA, DVI-D
LAN Controller	Intel 82579V
LAN	Gigabit Ethernet
