Intel DH61WW User Manual

v
Preface
This Technical Product Specification (TPS) specifies the board layout, components,
connectors, power and environmental requirements, and the BIOS for the
Intel
®
Desktop Board DH61WW.
Intended Audience
The TPS is intended to provide detailed, technical information about the Intel Desktop
Board DH61WW and its components to the vendors, system integrators, and other
engineers and technicians who need this level of information. It is specifically not
intended for general audiences.
What This Document Contains
Chapter Description
1 A description of the hardware used on the Intel Desktop Board DH61WW
2 A map of the resources of the Intel Desktop Board
3
The features supported by the BIOS Setup program
4 A description of the BIOS error messages, beep codes, and POST codes
5 Regulatory compliance and battery disposal information
Typographical Conventions
This section contains information about the conventions used in this specification. Not
all of these symbols and abbreviations appear in all specifications of this type.
Notes, Cautions, and Warnings
NOTE
Notes call attention to important information.
CAUTION
Cautions are included to help you avoid damaging hardware or losing data.

Intel DH61WW Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCIe 3.0 x16 Slots	0
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3.0 Gb/s Ports	4
USB 2.0 Ports	10
Audio Channels	6
Video Output	VGA, DVI-D
LAN Controller	Intel 82579V
LAN	Gigabit Ethernet
